Main Dimensions
Length o. a. 29,35 m
Length WL 27,75 m
Breadth moulded 9,55 m
Breadth o. a. 10,05 m
Depth 5,00 m
Draught max. 4,20 m
Gross Tonnage 05 GT
Bollard Pull 41,90 t
Speed (100% MCR) 12,2 kn
Cruising Range (11,0 kn) abt. 3.750 nm

Accomodation
5 cabins (3 x single +2 x double)
1 lavatory + 2 seperate WC rooms
1 mess
1 galley with provision storage
1 storeroom with washing machine and dryer

Machinery, ship’s Equipment
L2 main engines, Deutz MWM
2 x 1.290 kW / 1.000 rpm
running on gas oil
2 Schottel azimut thrusters
SRP 1212 (Fixed Pitch)
2 gensets abt. 2 x 49,5 kW
running on gasoil
Electr. system 400 V / 230 V - 50 Hz, 24 V DC
1 oil fired boiler for heating, abt. 80 kW
2 starting air compressors, 16 m³/h, 30 bar
1 MOB with davit
2 life rafts

Navigation and Communikation Equipment
1 radar, 1 river radar,
1 gyro compass, 1 auto pilot,
GMDSS A1+A2, AIS, 2 x GPS, ECDIS,
1 DGPS, 1 echo sounder, Navtex, etc.

Towing Equipment
Forecaslte:
1 electr. anchor / towing winch,
80 m wire,
breakload lines: 1860 kN
Working Deck:
1 double towing winch,
2 x 700 m wire, ø 38 mm
breakload: 800 kN
nom. Pull: 150 kN
1 towing bollard
1 hydr. towing hook, 40 t
with quick release
4 Double bollards
