Main Dimensions
Length Overall 22,83m
Beam 7,36m
Draft 1,20m
Deck Space Up to 60m2
Displacement / GT 70t / 88GT

Crew 3
Pax 12
Vessel max. Speed 23
Service Speed 20
Propulsion 2x Waterjet

Details
Fuel 8,5m3
Fresh Water 1,0m3
Black Water 0,5 m3
Cargo Capacity Up to 10t
Deck Space FWD 30m2
Deck Space AFT 30m2
Deck Load 1,2t/m2
Vessel Range 475nm

Main Engines
Type (ME) 2x MAN V12-1400
Max Power 2088kW
Max RPM 2150

Generators
Type (AE) 2x Cummins Onan MSKBP

Max Power
Rescue / Medical Equipment
Liferafts 2x 20Persons
Immersion Suits15
Life Vests 15x Fixed
POB Equipment 1x Jason’s Cradle
Safety Zone with David
Apotheke C1 Incl. AED

Other Equipment
Crane Palfinger PK 6500M
Winch Pull 0,79t @ 9,51m
1,11t @ 7,21m
1,19t @ 6,85m
Hook Load 0,82t @ 9,83m
1,13t @ 7,53m
1,76t @ 5,23m

Accommodation
Crew 3 Max
Pax 12 Seats

Propulsion
Type 2x Rolls Royce JET FF550

Bridge Equipment
(Acc. MED / SOLAS)
ECDIS FURUNO FMD 3100
Radar 2x FURUNO FAR-1518

AIS FURUNO FA-150
GPS FURUNO GP-170
Compass FURUNO SC-70
VHF 2x Sailor 6222 VHF with DSC

MF/HF FURUNO FS-2575
EPIRB JOTRON Tron 60GPS

SART JOTRON Tron SART20
