Main Dimensions
Length Overall 26,77m
Beam 9,12m
Draft 1,50m
Deck Space Up to 108m2
Displacement / GT 73,55t

Crew 3
Pax 12
Vessel max. Speed 22
Service Speed 20
Propulsion 2x FP Propeller

Details
Fuel 8,5m3
Fresh Water 1,0m3
Black Water 0,5 m3
Cargo Capacity Up to 10t
Deck Space FWD 30m2
Deck Space AFT 30m2
Deck Load 1,2t/m2
Vessel Range 550nm

Main Engines
Type (ME) 2x Caterpillar C32
Max Power 1968kW
Max RPM 2100

Generators
Type (AE) 2x Cummins Onan MSKBN

Max Power Rescue / Medical Equipment

Liferafts 2x 20 Persons
Immersion Suits 15
Life Vests 15 x Fixed
POB Equipment 1x Jason’s Cradle
Safety Zone with David

Apotheke C1 Incl. AED

Other Equipment
Crane Palfinger PK 6500M
Winch Pull 0,53t @ 9,30m
0,67t @ 7,40m
0,92t @ 5,60m
1,36t @ 4,00m
3,14t @ 1,9m

Accommodation
Crew 3 Max
Pax 12 Seats

Propulsion
Type 2x Fixed Pitch Propellers

Bow Thruster 2x 50kW

Bridge Equipment
(Acc. MED / SOLAS)
ECDIS FURUNO FMD 3200
Radar 2x FURUNO FAR-22BB

AIS
GPS FURUNO GP-170
Compass
VHF 2x Sailor 6222 VHF with DSC

MF/HF FURUNO FS-2575
EPIRB JOTRON Tron 60GPS

SART JOTRON Tron SART20
