Main Dimensions
GT: 476 t
Length: O.A. 32.00 m
Beam: O.A. 11.60 m
Depth At Sides: 5.36 m
Draught (Loaded): 5.54 m

Tank Capacities
Fuel Oil 155.70 m³
Fresh Water 40.8 m³
Sewage Holding 3.80 m³
Oily Water 4.00 m³
Lubrication Oil 1.70 m³
Dispersant 8.20 m³
Foam 15.80 m³

Performances
Max. Bollard Pull 76.00 Ton (Approx.)
Static Bollard Pull 74.00 Ton (Approx.)
Speed 12 Knots

Propulsion System
Main Engines 2 X Cat 3512C D Rating
Total Power 2 X 2100 Kw @ 1600 Rpm
Azimuthing Stern Dr. 2 X Schottel Srp1515 Cp
Propellers 2600Mm Dia, Cu3 Material

Deck Equipment
Anchors & Chain 2X 495 Kg
(High Holding Power)
Total302,5 M Short Link Chain 20.5 Mm Gr 3

Auxiliary Equipment
Generator Set 2 X Cat C9 175 Ekw 1500 Rpm
Harbour Gen. 1 X Cat C4.4 86 Ekw 1500Rpm
Bilge Pump 1 Pcs 25,00 M3/H
Cooling Water System Sperre Pleat Heat Exchanger
Fresh Water System Electrical Hydrophore and Sewage Pump
Airconditioning: Central Air Handling Unit For Single Duct System Cap. 3.650 M3/Hr.
Life Raft 2X On Top Deck, 10 Persons
1 Rescue Boat
Life Saving Appliances (Lsa Approved)

Towing Equipment
Forecastle Winch: Sec Ten Horn Electric Frequency Controlled Anchor Combined Escort Towing Winch For Chain 22 Mm, U2 With Two Chain Wheels, Two Towing Drums And Two Warping Heads. Type: Efaetw – 22 U2 700 Kn Two Ten Horn Ratched Roller Chain Stoppers Type Rkr 22. Towing Hook Mampaey Quick Release Type Dcx. 70/100 Towing Pin Hydraulic Tow Pin Unit Aft Towing Winch: Sec Ten Horn Electric Frequency Controlled Towing Winch With One Towing Drum And One Warping Head. Type : Eftw – 700 Kn “800m wire length / 52mm diameter Spare drum below deck with 800m wire length / 52mm diameter

External Fire Fighting
Ffs Supply 1 Off Integrated Control System, Two Monitors, Including Clutch For 2 X Fifi Pump Connecting To Each Main Engine. 2X Approx. 1.314M3/H At 110 Mwc

Accommodation
Accommodation For 8 Persons, Mlc-Compliant High-Quality, Climate-Controlled
2 Single Cabins
3 Double Crew Cabins.

Nautical And Communication Equipment
JRC – Complying GMDSS A1 – A3 Area
Radar Jrc Jma-5212-6
Gps Compass Jrc Jlr-21
Gps Navigator Jrc – Jlr - 7500
Vhf Radio 2X Jrc – Jss -2150
INMARSAT C
Wind System Nasa Clipper
Ais Jrc – Jhs-183
Ecdis
Mobile Gsm Phone
Echosounder Jrc Jfe-380-22
Magnetic Compass Reflecta/1-120 Mm
Autopilot Navitron – Nt921 Mkii
Navtex Jrc Ncr-333
Eprib Jotron Tron 60S
Sart Jotron Tron Ais Sart
Searchlight Seematz, 24 V, 1000 W
